Develop Custom QGC Build for Adding and Modifying UI Components

Creating a custom build of QGroundControl (QGC) opens up a world of possibilities for tailoring the user interface (UI) and adding specialized features. This is particularly useful for specific drone applications, research projects, or educational purposes where the standard QGC functionality might not fully meet the requirements. This in-depth guide explores the process of developing a custom QGC build, focusing on adding and modifying UI components to create a truly personalized experience. We will cover the essential steps, from setting up the development environment to implementing custom UI elements and testing the final build. By following this comprehensive guide, you will gain the knowledge and skills necessary to unlock the full potential of QGC and create a bespoke ground control station solution.

Understanding the QGroundControl Architecture

Before diving into the customization process, it's crucial to grasp the fundamental architecture of QGC. QGroundControl, at its core, is a Qt-based application, which means it leverages the power and flexibility of the Qt framework for its UI and application logic. Qt is a cross-platform framework, allowing QGC to run seamlessly on various operating systems like Windows, macOS, Linux, and even Android. This cross-platform compatibility is a significant advantage, ensuring your custom QGC build can reach a wide audience.

The QGC architecture can be broadly divided into several key components:

UI Layer: This is the visual face of QGC, the part that users interact with directly. It's built using Qt Quick, a declarative UI language that allows for the creation of fluid and dynamic interfaces. Qt Quick uses QML (Qt Meta-Object Language) for defining the UI elements and their behavior. Understanding QML is paramount for customizing the QGC UI.
Application Logic Layer: This layer encompasses the core functionality of QGC, including communication with drones via MAVLink, mission planning, telemetry data processing, and flight control. The application logic is primarily written in C++, which provides the performance and low-level control needed for real-time drone operations.
MAVLink Communication Layer: MAVLink is the Micro Air Vehicle Link, a lightweight communication protocol used for exchanging data between the ground station (QGC) and the drone's autopilot. QGC's MAVLink layer handles the encoding and decoding of MAVLink messages, allowing for seamless communication and control of the drone.
Plugin System: QGC features a powerful plugin system that allows developers to extend its functionality without modifying the core codebase. Plugins can add new features, customize the UI, or integrate with external services. This modular approach makes QGC highly extensible and adaptable to various use cases.

By understanding these architectural components, you can better plan your UI customizations and determine the best approach for adding new features. For instance, if you want to add a new sensor display, you might create a QML-based UI element and integrate it with the MAVLink communication layer to receive and display the sensor data. Alternatively, for more complex functionalities, developing a plugin might be a more suitable option.

Setting Up the Development Environment

To embark on your custom QGC build journey, setting up the development environment correctly is the first crucial step. This involves installing the necessary tools and libraries, configuring the development environment, and obtaining the QGC source code. A well-prepared development environment will significantly streamline the customization process and prevent potential roadblocks down the line.

Installing Qt and Qt Creator

As QGroundControl is built using the Qt framework, installing Qt and Qt Creator is the foundational step. Qt Creator is a powerful integrated development environment (IDE) specifically designed for Qt development. It provides a comprehensive set of tools for code editing, debugging, UI design, and project management. You can download the Qt Online Installer from the official Qt website (https://www.qt.io/). During the installation process, ensure you select the appropriate Qt version (ideally the one recommended by QGC) and the necessary components, including Qt Creator, the Qt libraries for your target platforms (e.g., Qt for Desktop, Qt for Android), and the Qt development tools.

Obtaining the QGC Source Code

The QGC source code is hosted on GitHub, a popular platform for collaborative software development. To obtain the source code, you'll need to clone the QGC repository from GitHub. This can be done using Git, a version control system. If you don't have Git installed, you can download it from the Git website (https://git-scm.com/). Once Git is installed, open a terminal or command prompt and navigate to the directory where you want to store the QGC source code. Then, execute the following command:

git clone --recursive https://github.com/mavlink/qgroundcontrol.git

The --recursive flag ensures that all submodules, which are dependencies of QGC, are also cloned. This is essential for building QGC correctly.

Configuring the Build Environment

After cloning the repository, you need to configure the build environment within Qt Creator. Open Qt Creator and navigate to "File" -> "Open File or Project." Browse to the directory where you cloned the QGC repository and select the qgroundcontrol.pro file. This is the Qt project file that defines the QGC build process.

Qt Creator will then load the project and prompt you to configure the build settings. You'll need to select a kit, which specifies the compiler, Qt version, and target platform for your build. Choose the kit that corresponds to your desired target platform (e.g., Desktop Qt 5.15.2 MinGW 64-bit for Windows) and Qt version. You may also need to configure the build directory and other build settings as needed.

With the build environment configured, you should be able to build QGC by clicking the "Build" button in Qt Creator. This will compile the source code and create the executable files. If the build is successful, you're ready to start exploring the QGC codebase and making your customizations.

Adding Custom UI Components

Adding custom UI components to QGroundControl involves creating new QML files, integrating them into the existing UI structure, and connecting them to the application logic. This process allows you to extend the functionality of QGC and tailor the user interface to your specific needs. Whether you want to display custom sensor data, add new control widgets, or create entirely new views, understanding how to add UI components is key to customizing QGC.

Creating New QML Files

QML (Qt Meta-Object Language) is the language used to define the user interface in QGC. To add a new UI component, you'll typically start by creating a new QML file. This file will contain the visual elements of your component, such as buttons, text fields, images, and custom widgets. QML uses a declarative syntax, which makes it easy to describe the UI elements and their relationships. You can create a new QML file within Qt Creator by right-clicking on the project in the Projects view and selecting "Add New..." -> "Qt" -> "QML File (Qt Quick 2)."

When designing your QML component, consider its purpose and how it will interact with the rest of the QGC UI. Think about the layout, the visual style, and the data it will display or the actions it will trigger. You can use various QML elements to create your UI, including:

Rectangle: For creating basic rectangular shapes.
Text: For displaying text.
Image: For displaying images.
Button: For creating clickable buttons.
TextField: For creating text input fields.
Slider: For creating sliders.
ComboBox: For creating dropdown lists.
ListView: For displaying lists of data.

QML also supports custom components, which allow you to encapsulate reusable UI elements into separate files. This promotes modularity and makes it easier to maintain your UI code.

Integrating QML Components into the UI

Once you've created your QML component, you need to integrate it into the QGC UI. This involves adding your component to the appropriate place in the UI hierarchy. The QGC UI is structured as a tree of QML elements, so you'll need to find the right parent element to add your component to.

You can use Qt Creator's Design mode to visually inspect the QGC UI hierarchy and identify the appropriate parent element. Alternatively, you can explore the QML source code to understand the UI structure. The main QML files for the QGC UI are typically located in the src/ui directory.

To integrate your component, you'll need to import the QML file in the parent element's QML file and then instantiate your component as a child element. For example:

import QtQuick 2.0
import QGroundControl.Controls 1.0
import "MyCustomComponent.qml"

Column {
    width: parent.width
    height: parent.height

    MyCustomComponent {
        // Properties and settings for your component
    }

    // Other UI elements
}

Connecting UI Components to Application Logic

To make your UI component functional, you'll need to connect it to the application logic. This typically involves exchanging data between the UI and the C++ code that handles the core functionality of QGC. QML provides several mechanisms for connecting to C++ code, including:

Properties: You can expose C++ properties to QML, allowing you to read and write data from QML.
Signals and Slots: You can use Qt's signals and slots mechanism to send notifications from C++ to QML and vice versa. This is a powerful way to handle events and asynchronous operations.
Q_INVOKABLE Methods: You can declare C++ methods as Q_INVOKABLE, making them callable from QML.

To connect your UI component to the application logic, you'll typically create a C++ class that handles the data and functionality for your component. You can then expose properties, signals, and slots from this class to QML, allowing your QML component to interact with the C++ code.

For example, you might create a C++ class that receives sensor data from MAVLink and exposes it as properties. Your QML component can then bind to these properties to display the sensor data in the UI. Similarly, you can use signals and slots to handle user interactions, such as button clicks, and trigger actions in the C++ code.

Modifying Existing UI Components

In addition to adding new UI components, you might also want to modify existing ones to customize QGroundControl to your specific needs. This could involve changing the appearance of a component, adding new functionality, or altering its behavior. Modifying existing UI components requires a good understanding of the QGC UI structure and the QML code that defines the components.

Identifying the Component to Modify

The first step in modifying an existing UI component is to identify the specific component you want to change. This can be done by visually inspecting the QGC UI and using Qt Creator's Inspect mode to examine the UI hierarchy. Inspect mode allows you to click on a UI element and see its properties and its parent elements in the UI tree.

Alternatively, you can explore the QML source code to find the component you want to modify. The QGC UI code is organized into a directory structure, with different directories for different parts of the UI. The main QML files for the UI are typically located in the src/ui directory.

Once you've identified the component, you'll need to find the QML file that defines it. The file name usually corresponds to the component name, and the file is located in the appropriate directory for that component.

Understanding the QML Code

Before making any changes, it's crucial to understand the QML code that defines the component. QML uses a declarative syntax, which means that the UI elements and their properties are declared in the code. The code also includes bindings, which define how the properties of the elements are connected to each other and to the application logic.

Take the time to read through the QML code and understand the structure of the component, the properties it uses, and the bindings that are defined. Pay attention to the layout of the elements, the visual styles, and any event handlers that are present.

Making the Modifications

Once you understand the QML code, you can start making your modifications. This might involve changing the properties of the elements, adding new elements, or modifying the bindings. When making changes, it's important to follow the QML syntax and ensure that your changes don't break the component or the rest of the UI.

If you're adding new functionality, you might need to connect your changes to the application logic. This could involve adding new properties, signals, or slots to the component and connecting them to the C++ code. As with adding new UI components, you can use the mechanisms described earlier for connecting QML to C++.

Testing the Changes

After making your modifications, it's essential to test them thoroughly to ensure that they work as expected and don't introduce any new issues. Build and run QGC with your changes and interact with the modified component to verify its functionality.

Pay attention to the visual appearance of the component, its behavior, and its interactions with other parts of the UI. If you encounter any issues, use Qt Creator's debugging tools to identify the cause and fix the problem. Testing your changes thoroughly will help you ensure that your custom QGC build is stable and reliable.

Testing and Debugging the Custom Build

Testing and debugging are integral parts of the development process for any software application, and QGroundControl is no exception. A custom build, with its added and modified UI components, necessitates rigorous testing to ensure stability, functionality, and a seamless user experience. A comprehensive testing strategy will identify potential issues early in the development cycle, saving time and effort in the long run. Furthermore, effective debugging techniques are crucial for pinpointing and resolving any problems that arise during testing.

Setting Up a Testing Environment

Before commencing testing, it's essential to establish a suitable testing environment. This environment should closely mimic the conditions under which the custom QGC build will be deployed in real-world scenarios. Consider factors such as the operating system, hardware specifications, and the type of drone or vehicle the QGC build will interact with. Ideally, you should have a dedicated testing machine or virtual machine to isolate the testing process from your development environment.

For UI testing, it's beneficial to have a variety of screen resolutions and display settings to ensure that your custom UI components render correctly across different devices. If your QGC build interacts with a drone or vehicle, you'll need to set up a simulation environment or conduct real-world flight tests in a controlled setting.

Implementing a Testing Strategy

A well-defined testing strategy is crucial for identifying and addressing potential issues in your custom QGC build. This strategy should encompass various types of testing, including:

Unit Testing: Unit tests focus on individual components or modules of your code. They verify that each component functions correctly in isolation. Unit tests are typically automated and can be run frequently during development.
Integration Testing: Integration tests verify the interaction between different components or modules of your code. They ensure that the components work together correctly as a system. Integration tests are often more complex than unit tests and may require setting up dependencies between components.
UI Testing: UI tests focus on the user interface of your QGC build. They verify that the UI components render correctly, respond to user input as expected, and provide a seamless user experience. UI tests can be performed manually or automated using tools like Qt Test.
System Testing: System tests verify the overall functionality of your QGC build as a complete system. They ensure that all components work together correctly and that the system meets its requirements. System tests often involve simulating real-world scenarios and use cases.

Debugging Techniques

When issues arise during testing, debugging is essential for pinpointing the cause and implementing a solution. Qt Creator provides a powerful debugger that allows you to step through your code, inspect variables, and identify errors. Some common debugging techniques include:

Breakpoints: Breakpoints allow you to pause the execution of your code at specific locations. This enables you to examine the state of your application and identify the source of a problem.
Stepping: Stepping allows you to execute your code one line at a time. This is useful for tracing the flow of execution and identifying the point at which an error occurs.
Inspecting Variables: The debugger allows you to inspect the values of variables at runtime. This can help you understand the state of your application and identify unexpected values.
Logging: Logging involves adding print statements to your code to output information about the execution flow and the values of variables. This can be helpful for identifying errors that are difficult to reproduce in a debugger.

By employing a robust testing strategy and utilizing effective debugging techniques, you can ensure that your custom QGC build is stable, reliable, and provides a positive user experience.

Conclusion

Developing a custom build of QGroundControl for adding and modifying UI components offers a powerful way to tailor the ground control station to specific needs and applications. By understanding the QGC architecture, setting up the development environment correctly, and mastering the techniques for adding and modifying UI elements, you can create a truly personalized experience. Thorough testing and debugging are essential to ensure the stability and functionality of your custom build. With dedication and the knowledge gained from this guide, you can unlock the full potential of QGC and create a bespoke ground control station solution that meets your unique requirements. The ability to customize QGC opens doors to innovation and allows for the creation of specialized tools for a wide range of drone-related activities, from research and development to commercial applications and beyond.
